A concrete slab over metal deck bears on a steel beam connected with three-sixteenths inch fillet welds at twelve inches typically. A standard beam connection at the column beyond connects per detail one on sheet S eight hundred two. A collector beam connection at the column beyond connects per detail one on sheet S two hundred fifty-two, unless noted otherwise. A metal deck wall system is provided by the steel stud supplier.
STL BM BM 3/16 2-12 TYP S601 7 TYP S701 13 MTL DECK WALL SYSTEM BY STL STUD SUPPLIER STL BM CONC OVER MTL DECK COLLECTOR BEAM CONN AT COL BYND PER DET , UNO / (1 S252) STANDARD BEAM CONN AT COL BYND PER DET / (1 S802)
