Typical steel deck bearing support angles and diagonal L3x3x1/4 braces frame into structural steel columns or hollow structural section columns and steel beams or girders. Trim angles with variable leg sizes are provided as required. Connections are secured using 3/16 fillet welds with a 2-inch minimum length specified at each end. Typical steel beams or girders intersect the column assemblies with bolted connections.
L3x3x1/4 BRACE, TYP STL COL STL BM OR GIRDER, TYP HSS COL STL BM OR GIRDER, TYP L3x3x1/4 DECK BRG SUPPORT, TYP 3/16 2" MIN TYP, EA END 3/16 2" MIN TYP, EA END TRIM ANGLE LEG AS REQ'D
