The control joint assembly consists of an upper one-eighth-inch sawcut extending to one-quarter of the slab depth, spaced and filled with mastic, completed within four to twelve hours of pouring the slab. The construction joint assembly incorporates smooth dowels measuring three-quarters of an inch by eighteen inches at twenty-four inches on center, with a snug-fitting twenty-four gauge metal sleeve on one side of the joint and two continuous number four reinforcing bars. The concrete slab features a thickness profile with a two-inch minimum clearance at the top and a three-inch clearance at the bottom, centered around thickened edges with nine-inch transition zones and two-foot sloped approaches.
2'-0" 2'-0" 2" MIN. TYPICAL CONTROL JOINT FOR SLAB ON GRADE BREAK 1/2 REINF. SMOOTH DWL 3/4"x18" @ 24" O.C. SNUG FITTING 24 GA. MTL SLEEVE ON ONE SIDE OF JT TYPICAL CONSTRUCTION JOINT FOR SLAB ON GRADE 9" 9" "T" 1/4 x "T" + 1" TOOLED J\T R=1/8" (2) #4 CONT. EQ. EQ. 1/8" SAWCUT x 1/4 SLAB DEPTH - SAW WITHIN 4 TO 12 HOURS OF POURING SLAB - FILL W/ MASTIC 3" CLR 2" CLR
