An open web steel joist bears against a continuous metal stud wall framing assembly. The joist connects with four number eight screws through connection plates, sized per plan. A continuous track caps the upper metal studs, and metal stud blocking is detailed below the joist bearing. Metal stud sizing is referenced to the schedule, and finishes and suspended ceilings are coordinated per architectural drawings.
