A composite slab on metal deck bears against a three-inch-thick concrete wall with a roughened surface to one-quarter-inch amplitude. Form saver reinforcing bars with standard hooks tie the slab reinforcement into the wall per the structural plans, maintaining a one-inch clear cover. An optional construction joint is detailed at the top of the wall. Additional connection details are referenced to sheet S51-00.
CONN. PER 7 S51-00 t.1 b.1 3" CONC. WALL - FOR REINF. SEE EL.'S ROUGHEN SURFACE TO 1/4" AMPLITUDE SLAB ON MTL DECK - FOR REINF. SEE SLAB PLANS OPTIONAL C.J. - TOP OF WALL AT SIM. FORM SAVER W/ STD HOOK 1" CLR. PER PLAN
