An HSS roof beam connects to an HSS6x6 column and bears on a continuous L3x3x3/16 angle ledger. Roof deck spans across the assembly with a 3/16 fillet weld connection. A continuous ledger angle supports the beam condition above window heads sized per architectural drawings.
ROOF DECK, SEE PLAN SEE PLAN HSS BEAM, SEE PLAN 3/16 3-12 L3x3x3/16 CONT LEDGER ROOF DECK, SEE PLAN NOT APPLIC @ SIM WINDOWS, SEE ARCH'L HSS6x6 COL, SEE PLAN 1-12
