Additional hooked reinforcing bars lap with the main slab reinforcement using a Class B splice and match the size and spacing of the adjacent slab reinforcement. The concrete slab features a localized depression with a thickened subgrade section supported on compacted subgrade. Two-inch concrete clearance is maintained typically for reinforcement. Curb locations and dimensions are coordinated with architectural drawings.
1 6 1 6 ADD'L. HOOKED BAR. CLASS B LAP W/ SLAB REINF. MATCH SIZE AND SPACING OF SLAB REINF. SEE ARCH. FOR CURB LOCATIONS AND DIMENSIONS. - SEE FOR REINF. SLAB DEPRESSION - SEE PLAN MATCH SLAB SECTION AND SUBGRADE. - SEE 1 S-155021 4 S-155021 TYP. 2" CLR.
