A wood beam header is supported by a wood post using an EPC post cap. A structural strap ties the header to the 3x or 4x wood blocking as required by the plans. A shear panel aligns with the framing assembly, and the strap is centered over the post connection.
EQ. EQ. BEAM / HEADER PER PLAN EPC POST CAP WOOD POST SHEAR PANEL PER PLANS 3X/4x BLKG. AS REQ'D. STRAP PER PLAN C.L. OF STRAP TYPICAL 'MST' DRAG STRAP AT HEADER TO 3x/4x BLOCKING
