A continuous top track is spliced at the centerline with a nested stud section matching the width and gauge of the main track. Six number ten self-drilling screws are fastened through each flange on each side of the splice. Wall studs connect into the track assembly at specified spacings.
CONTINUOUS TOP TRACK BETWEEN SPLICE AND WALL ENDS CL OF TOP TRACK SPLICE WALL STUD REF. SCHEDULE (6) #10 SCREWS EACH FLANGE EACH SIDE OF SPLICE TOP TRACK REF. SCHEDULE STUD SECTION NESTED IN TOP TRACK WIDTH AND GUAGE TO MATCH TOP TRACK SECTION A-A A A 8" 8"
