An aluminum rectangular tube column sized per plan supports continuous aluminum beams sized per plan with a 5/8-inch aluminum plate typical at the bearing interface. The aluminum beams feature bolted web splice connections detailed per sheet S510, with typical 1 1/2-inch dimensions. Bolted fasteners secure the framing members and connection plates.
AL RT 6x6 COL PER PLAN AL BEAM PER PLAN AL PL 5/8 1'-2" (TYP) 1 1/2" 7 - TYP S510
