Metal stud framing bears on a continuous track anchored directly to a concrete slab or curb. The continuous track matches the stud size and gauge, featuring a one and one-half inch flange. One-quarter inch diameter concrete screws with a one and eighteen-hundredths inch effective embedment secure the track at eighteen inches on center, maintaining a three-inch minimum edge distance. Number ten screws fasten each side of the track to each vertical stud.
DISTANCE 3" MIN. EDGE METAL STUD FRAMING REF. ELEVATIONS #10 SCREW EACH SIDE TO EACH STUD 1/4"Ø CONCRETE SCREW w/ 1.18" EFFECTIVE EMBEDMENT @ 18" o.c. CONCRETE CONTINUOUS TRACK MATCH STUD SIZE AND GAUGE w/ 1 1/2" FLANGE CONCRETE CURB WHERE OCCURS REF. PLAN
