A crane support steel beam and rail supplied by the crane manufacturer rest on a typical W12x65 structural steel haunch connected to a steel column. A steel framing beam sized per plan connects to the column flange using a bolted shear tab connection. A concrete floor slab poured over a metal floor deck bears on the structural steel beam.
7 S601 2 S513 BEAM AND RAIL BY CRANE SUPPLIER CRANE SUPPORT STEEL BEAM, SEE PLAN CONCRETE OVER METAL FLOOR DECK, SEE PLAN COORDINATE WITH CRANE SUPPLIER W12x65 HAUNCH - TYP 5
