Cold-formed steel studs connect to the structural framing using TSN Verticlip LB600 clips fastened with four number twelve screws into each stud, secured with three powder-actuated fasteners. The steel studs align with a wide-flange beam supporting a roof deck sized per structural schedules. An L2 by 2 by 18 gauge angle spaced at thirty-two inches on center attaches to the beam with two powder-actuated fasteners and connects to the assembly using two number twelve screws.
ROOF DECK - SEE SCHEDULE FOR SIZE AND ATTACHMENT L2 x 2 x 18 ga. @ 32"o.c. (2) PAF'S W BEAM - SEE PLAN TSN VERTICLIP LB600 @ EACH STUD W/ (4) #12 SCREWS INTO EACH STUD (3) PAF'S STEEL STUDS - SEE ELEVATIONS, SCHEDULE, OR EXTERIOR FRAMING NOTES (2) #12 SCREWS
