S-S67JP — Detail

Structural · S-S67JP

Detail

Units: metric
Sheet: S3.3
Discipline: Structural

About this detail

The drawing consists of textual notes detailing structural requirements. It specifies that welded shear studs and decking attachments shall not be placed on beam flanges within the protected zone. Additionally, it restricts welded, bolted, screwed, or shot-in attachments for perimeter edge angles, exterior facades, partitions, ductwork, piping, or other construction within the protected zone.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
