A beam-to-column connection featuring an optional three-quarter inch gap for columns with a flange width of twelve inches or greater. The connection utilizes top and bottom plates sized per the standard schedule, with a minimum connection plate thickness equal to the standard bolted beam connection schedule plus one-sixteenth of an inch. Bolts are arranged with standard spacing and diameters as specified by the standard bolted beam connection schedule, referencing AISC Table 10-10a. Fillet welds secure the plates with notes referencing specific welding requirements.
T/STL A 3/4" GAP MAY BE USED AS AN OPTION FOR COLUMNS WITH bf = 12" OR GREATER W W NOTE 4 2x BOLT Ø MIN CONN PL THICKNESS PER STD BOLTED BM CONN SCHED PLUS 1/16" NUMBER OF BOLTS REQ'D PER STD BOLTED BEAM CONN SCHED PL T&B, PER SCHED COL FLANGE CUT AWAY FOR CLARITY 3" TABLE 10-10a "L" PER AISC TYP UNO 2 3/4" ELEVATION
