A cold-formed metal stud wall assembly bears on a continuous six-inch 16-gauge track secured with powder-actuated fasteners spaced at twenty-four inches on center. The track supports six-inch 18-gauge metal studs spaced at sixteen inches on center with exterior sheathing and finish applied per architectural drawings. The entire assembly sits atop a concrete over metal floor deck spanning across a structural steel beam sized per plan.
STEEL BEAM, SEE PLAN CONCRETE OVER METAL FLOOR DECK, SEE PLAN 6"x16GA (600T125-54) xCONT TRACK WITH PAF AT 24" O.C. 6"x18GA (600S162-43) METAL STUDS AT 16" O.C. EXTERIOR SHEATHING AND FINISH, SEE ARCH
