A hollow structural section strut connection utilizes welded gusset plates and embedded steel plates within a concrete assembly. The connection incorporates 1/4-inch and 5/16-inch fillet welds, low-hydrogen welding electrodes, and embedded reinforcing bars including three or four #6 bars at 5 feet zero inches long. Epoxy grout is specified after welding at the 4x4-W2.1xW2.1 welded wire fabric. The assembly includes 1/2-inch and 3/4-inch steel plates sized per plan to transfer loads between the HSS strut and the concrete support.
4x4-W2.1xW2.1 WWF W/ EPOXY GROUT AFTER WELD HSS PER PLAN (WHERE OCCURS) HSS PER PLAN (WHERE OCCURS) 4" LO HYD 1/4 10" 1/4 1/4 10" C - D - 2" CL 8" PL 1/2"x7 3/4"x2'-0" PL 1/2"x8"x1'-2" ROOF SHEATHING PL 1/2"x10"x1'-4" W/ (3) #6 x5'-0" LONG 1/4" GUSSET PL 1/4 1/4 5/16 3 SIDES 3/8 2" 6" 6" 2" 6" 6" 3" 3" 6" PL 3/4"xt"x2'-0" W/ (4) #6x5'-0" LONG ROOF SHEATHING PLATE 3/8"x7 3/4" (TYP) LO HYD (TYP) LO HYD (TYP) 1/4 1/4 TYP 2 1/2" 1/4" GUSSET PL 1/4 HSS FLAT SEE PLAN 1/4 2 1/2" 5" P.P. 3" CLR PLAN VIEW D SECTION C SECTION
