These details illustrate typical structural steel connections for beam-to-column flange and beam-to-beam configurations. The supported beams connect via shear plates sized per schedule with standard bolt groupings and edge distances. Top and bottom plates are provided with a thickness matching the shear plate where indicated, alongside partial height stiffener plates matched in thickness to the shear plate and secured with six or more bolts.
BEAM TO COLUMN FLANGE 2 SIDED BEAM TO BEAM SEE SCHED. AISC MIN. AISC MIN. 3" TYP. SEE SCHED. COLUMN k 1 (+1/2") DISTANCE -0" 3" MAX. AISC MIN. AISC MIN. TYP. SEE SCHED. 3" AISC MIN. AISC MIN. 3" 2d b SEE SCHED. AISC MIN. AISC MIN. PLATE TOP AND BOTTOM THICKNESS TO MATCH SHEAR PLATE THICKNESS PROVIDE PARTIAL HEIGHT STIFF PLATE ('t' TO MATCH 't' OF SHEAR PLATE) THIS SIDE, WITH 6 BOLTS OR MORE 3" 3" 3" 3" 3" 3" 3" 3" 2d b 2d b 2d b
