A wide-flange beam connects to a wide-flange column web using a web plate and structural bolts typically spaced at three and a half inches maximum. Fillet welds join the connecting elements with typical edge distances specified for the bolts.
BEAM TO WIDE FLANGE COLUMN WEB PLATE CONNECTION WEB PL 2 3 1/2" MAX 3 BOLT SPACING AND EDGE DIST, TYP 5 TYP
