A steel beam framed with an L3x3x1/4 angle connects to a fourteen-inch concrete wall reinforced with vertical and horizontal bars sized per plan. The wall incorporates an 8 inch by 4 inch by 3/8 inch embed plate anchored by two 3/4 inch diameter by 5 inch headed stud anchors spaced at 24 inches on center. A concrete topping over a metal floor deck bears adjacent to the wall assembly. The steel beam web is bolted with a vertical row of five fasteners.
L3x3x1/4 STEEL BEAM SEE PLAN EMBED PL 8"x4"x3/8" w/ (2) 3/4Ø x 5" HSAs AT 24" oc CONC OVER MTL FLR DECK, SEE PLAN 14" CONC WALL SEE PLAN SEE ARCH FOR WALL ABOVE 8 1/4 HORIZ WALL REINF VERT WALL REINF
