A buckling-restrained braced frame connection joins a frame beam and frame column with a gusset plate. A doubler plate and continuity plates are provided at the column as required by the manufacturer, with continuity plate welds designated as demand critical. An erection plate facilitates field assembly, while one-half-inch minimum stiffener plates are located on both sides to align with the edge of the gusset plate. Free edge stiffeners are added where required, and the gusset plate and brace connections are designed per the buckling-restrained brace manufacturer specifications using standard fillet welds.
CONTINUITY PLATE PER "TYPICAL CONTINUITY PLATE DETAIL". WELDS ARE DEMAND CRITICAL WP DOUBLER PLATE AS REQUIRED PER BRB MANUF FRAME COLUMN SEE ELEVATION GUSSET PLATE AND WELDS AS DESIGNED BY BRB MANUF FREE EDGE STIFFENERS WHERE REQUIRED PER BRB MANUF BUCKLING RESTRAINED BRACE DESIGNED BY BRB MANUF FRAME BEAM SEE ELEVATION ERECTION PLATE 1/2" MIN STIFF PLATE BOTH SIDES TO ALIGN WITH EDGE OF GUSSET TYP AT BEAM & COLUMN CL OF COLUMN 5/16 3 SIDES, TYP C.P. WEB C.P. T&B FLANGE
