Steel framing members connect via a W12x19 brace typically used on each side unless noted otherwise. Three-eighths-inch stiffener plates weld to both sides with a three-eighths-inch fillet weld typical on all sides. Framing members size per plan with a maximum three-foot offset dimension.
PLAN W12x19 TYP UON BEAM SEE PLAN 3/8" STIFF PL EACH SIDE 2 1 BEAM SEE PLAN (3'-0" MAX) SEE PLAN 3/8 TYP ALL SIDES
