A drop-in steel beam frames into a hollow structural section column size HSS 5x5x3/16 with a connection welded using three-sixteenths fillet welds. The assembly incorporates cold-formed metal studs measuring six inches by eighteen gauge at sixteen inches on center typically, bounded by continuous top and bottom tracks. A metal roof deck bears on the steel beam, and a diagonal brace connects per detail eight on sheet S511 at six feet on center. Exterior finishes and window head heights are coordinated per architectural drawings.
6"x16GA (600T125-54) x CONT BOTTOM TRACK 6"x16GA (600T125-43) x CONT TOP TRACK 6"x18GA (600S162-43) METAL STUDS AT 16" O.C. TYPICAL STEEL BEAM, SEE PLAN METAL ROOF DECK T.O. WINDOW - TYP. BRACE PER 8/S511 AT 6'-0" O.C. 3/16 3/16 EXTERIOR FINISH, SEE ARCH HSS5x5x3/16 12A S511 12C S511 10 S521 SEE ARCH
