An L4x4x1/2 by 1'-0" angle bracket attaches to a wide-flange girt with two 3/4" diameter A325-SC bolts. A continuous 1/2" bent plate connects to the assembly with a 3/16" fillet weld, while quarter-inch fillet welds secure the bracket with continuous grinding smooth at the joint. The hangar door and wall panels interface adjacent to the structural framing per architectural drawings.
R6 S-563 W GIRT PER EL HANGAR DOOR PER ARCH DWG A-422 1/4 4 3/16 L4X4X1/2X1'-0" BRACKET W/ (2) 3/4" DIA A325-SC BOLTS CONT GRIND SMOOTH WALL PANEL PER ARCH DWG A-351 - A-353 CONT BENT PL1/2 3" 4" 1/4 4
