A slab-on-grade construction joint utilizes a diamond-shaped load plate to transfer shear loads between adjacent concrete pours. The assembly sits atop compacted subgrade and comprises a first slab placement and a second slab placement meeting at a vertical joint line. Reinforcing steel is discontinued at the joint location to allow independent slab movement. A diamond dowel load plate is embedded mid-depth at T/2, with sizing and on-center spacing determined by the slab thickness T per the accompanying schedule.
FIRST SLAB PLACEMENT (SEE PLAN) REINFORCING STEEL (AS OCCURS) DIAMOND DOWEL LOAD PLATE -SEE SCHEDULE FOR PLATE SIZE AND SPACING T SECOND SLAB PLACEMENT (SEE PLAN) DISCONTINUE BAR AT JOINT LOCATION CONSTRUCTION JOINT T/2 T/2 DIAMOND SHAPED LOAD PLATE SCHEDULE SLAB DEPTH, T (in.) 5 TO 6 7 TO 8 9 TO 11 1/4 x 4 1/2 x 4 1/2 3/8 x 4 1/2 x 4 1/2 3/4 x 4 1/2 x 4 1/2 18 18 20 DIAMOND LOAD PLATE DIMENSIONS (in.) DIAMOND PLATE OC SPACING (in.)
