Concrete tilt-up wall panels are reinforced with vertical and horizontal reinforcement bars placed in single or double mats as specified in structural schedules and elevations. Panels feature equal spacing for vertical and horizontal reinforcement, with specific clearances required for double-mat configurations. Architectural reveals or recesses modify the panel profile, requiring coordination with architectural drawings for dimensions and locations.
EQ. SINGLE MAT PANELS w/ REVEALS OR RECESSES SINGLE MAT PANELS w/OUT REVEALS HORIZONTAL PANEL REINF EQ. REVEAL OR RECESS - SEE ARCH. FOR MORE INFORMATION VERT. PANEL REINF. VERT. CONC PANEL REINF. DOUBLE MAT PANELS w/ REVEALS OR RECESSES DOUBLE MAT PANELS w/OUT REVEALS HORIZONTAL PANEL REINF CLEARANCE REQ'D BY SCHEDULE, SEE 20/S401 CONC TILT-UP WALL PANEL - SEE SCHEDULES AND ELEVATIONS CLEARANCE REQ'D BY SCHEDULE, SEE 20/S401
