A concrete slab on grade features a thickened slab edge adjacent to an existing concrete beam, separated by an isolation joint. A stem wall and thickened slab edge occur at the slab step condition. The assembly bears above compacted structural backfill over an existing tunnel lid with a maximum depth of eight feet, situated above an existing sloped concrete slab over an escalator.
THICKENED SLAB EDGE ADJ TO (E) CONC BM ISOLATION JT (E) CONC BM CONC SOG (E) SLOPED CONC SLAB OVER ESCALATOR COMPACTED STRUC BACKFILL OVER (E) TUNNEL LID (MAX DEPTH = 8'-0") (E) CONC SLAB AT TUNNEL LID STEM WALL AND THICKENED SLAB EDGE AT SLAB STEP (WHERE OCCURS)
