A fixed aluminum window rests above a perimeter steel channel designated as architecturally exposed structural steel level C2 and P2, secured with a metal clip. A cover cap finishes the assembly, and dimension points reference exterior elevations. Face of brick appears beyond the sill assembly.
STOREFRONT # ST01 DIM POINT REFER TO ELEVATIONS DIM POINT F.O. BRICK (BEYOND) 1 1/2" 1'-0" 1/2" PERIMETER STEEL CHANNEL - AESS LEVEL C2, P2 METAL CLIP COVER CAP FIXED ALUMINUM WINDOW 4" 4"
