Offset framing is provided where structural ceiling supports encounter an obstruction, utilizing L2x3x18 gauge clip angles secured with three number 10 self-tapping metal screws on each leg. The framing coordinates with architectural studs and maintains a five and five-eighths inch offset from the ceiling line. Additional framing requirements and unshown information are coordinated per architectural drawings.
L2x3x18GA CLIP LLV w/ (3) #10 SMS EA LEG LINE OF CEILING, SEE ARCH STUDS SEE ARCH & NOTE: FOR INFORMATION NOT SHOWN OR NOTED, SEE . 2 S6.02 1/S6.03 5 5/8" WHERE OBSTRUCTION OCCURS, PROVIDE OFFSET FRAMING; FOR ADDITIONAL INFO, SEE 3 S6.03 3 S6.03 OBSTRUCTION WHERE OCCURS APPLICABLE TO ALL DRAWINGS UNLESS NOTED OR SHOWN OTHERWISE TYPICAL DETAILS
