A reinforced concrete pile cap is supported by multiple steel piles and a central concrete column. The assembly features an existing twenty-two-inch by twenty-two-inch concrete column flanked by an array of structural steel piles and twelve-inch diameter concrete piles. Reinforcement consists of number nine bars spaced at twelve inches on center in both top and bottom layers, along with supplementary confining steel. Comprehensive dimensions establish the precise layout and spacing of the piles and structural elements across the sixteen-foot-six-inch by nine-foot-two-inch footprint.
