Steel roof deck panels are secured to supporting structural framing with five-eighths inch diameter puddle welds per structural notes. Parallel edge conditions feature an edge closure of the same gauge as the deck fastened with number ten screws at four inches on center. Roof deck seams utilize one and one-half inch long top seam welds. Interior and exterior bearings show standard deck laps of four inches over joists or steel beams. Roof deck openings under sixteen inches use an L three by two by one-quarter by three-foot eight-inch long leg horizontal angle centered on the opening, secured with three one-half inch self-drilling screws in two valleys on each side of the opening.
1'-4" MAX. EACH WAY ROOF DECK OPENING < 16" FRAMING AT DECK OPENING SEAM INTERIOR BEARING EXTERIOR BEARING PARALLEL EDGE / EDGE CLOSURE (3) 1/2" SELF DRILLING SCREWS IN (2) VALLEYS EACH SIDE OF OPENING L3x2x1/4x3'-8" LLH CENTERED ON OPENING JOIST OR STEEL BEAM 1 1/2" LONG TOP SEAM WELDS, SEE NOTES. 5/8" Ø PUDDLE WELDS SEE NOTES 5/8" Ø PUDDLE WELDS SEE NOTES LAP 4" 5/8" Ø PUDDLE WELDS SEE STRUCTURAL NOTES EDGE CLOSURE SAME GAUGE AS DECK No. 10 SCREWS @4"OC STEEL ANGLE SEE PLAN FOR SIZE JOIST TOP CHORD EDGE MEMBER EDGE MEMBER 1/2" MAX 5 TYPICAL STEEL ROOF DECK DETAILS
