A continuous L3x3x1/4 angle bearing detail supports a concrete floor slab over a metal deck framing into a steel beam, oriented perpendicular to the deck flutes. A continuous three-sixteenths inch fillet weld secures the assembly. The steel beam connects to a cold-formed metal stud wall detailed per architectural drawings.
CONCRETE OVER METAL FLOOR DECK, SEE PLAN METAL STUD, SEE ARCH. STEEL BEAM, SEE PLAN 3/16 TYP 3/16 3-12 3-12 DECK BRG L3x3x1/4 x CONT, PERPENDICULAR TO DECK FLUTES
