A davit socket pedestal is mounted atop a structural steel beam sized per plan, offset at the column connection. A half-inch by four-inch plate, sized to the beam width plus one inch, connects with a quarter-inch fillet weld to the beam flanges. Three-eighths-inch stiffener plates are welded to each side of the column web with quarter-inch fillet welds connecting the beam web to the stiffener plates.
(OFFSET AT COLUMN) DAVIT SUPPORT AT BEAM D PL 1/2"x4"x BEAM WIDTH +1" w/ 1/4" FILLET WELD TO FLANGES (SEE DETAIL E FOR COL ROTATED 90°) BEAM SEE PLAN DAVIT SOCKET PEDESTAL 3/8" STIFF PL EACH SIDE COLUMN SEE PLAN 1/4 1/4 BEAM WEB TO STIFF PL
