A concrete slab over metal floor deck bears on a steel beam supported by a primary steel beam with a web stiffener. The connection features a bolted framing angle detail with dimensions providing a one-half inch offset and a twelve to twenty-eight inch spacing range. Adjustments are made as needed for architectural clearance per general structural notes. Additional structural bracing elements are referenced by detail callouts.
CONC OVER MTL FLR DECK 1/2" 12" < L ≤ 28" STL BM STL BM WEB STIFF, SEE GSN A1 S302 C4 S601 FOR ARCH CLEARANCE ADJUST AS NEEDED
