An architectural ceiling grid supports an acoustical ceiling tile and a luminaire hung via independent suspension wires and manufacturer mounting hardware. Luminaire suspension wires must remain separate from ceiling hangers, secured with a minimum of three twists. Independent luminaire diagonal bracing wires and independent ceiling diagonal bracing wires provide lateral stability. A fixture whip connects from a junction box with a maximum length of six feet. Installation follows the manufacturer's mounting instructions and recommended hardware.
LUMINAIRE SUSPENSION WIRES, TYP. MUST BE SEPARATE FROM CEILING HANGERS. 3 TWIST MIN. (TYP) FIXTURE WHIP FROM JUNCTION BOX. (6' LONG MAX.) LUMINAIRE MFR'S MOUNTING HARDWARE. ACOUSTICAL CEILING TILE (TYP) ARCHITECTURAL CEILING GRID NOTE: 1. INSTALL IN ACCORDANCE WITH MANUFACTURER'S MOUNTING INSTRUCTIONS AND USING THE RECOMMENDED MOUNTING HARDWARE. LUMINAIRE. REFER TO LIGHTING FIXTURE SCHEDULE. CEILING HANGER WIRE, TYP. INDEPENDENT LUMINAIRE DIAGONAL BRACING WIRE INDEPENDENT CEILING DIAGONAL BRACING WIRE
