The detail illustrates multiple views of a structural steel set back connection utilizing a W200x42 beam framing into an HSS 102x102x6.4 column. Components include flat bars (FB), angles (L 102x102x13), hex bolts (M10), nuts, and flat washers. Dimensions and set back parameters are clearly marked throughout the views.
Text on the drawing
FB 6.4x38 x181 LG 300W, FB 6.4x58 x100 LG 300W, 2-HEX NUT M10 C\W. FLAT WASHER 4-HEX NUT M10 C\W. FLAT WASHER 100 1262 1143 SET BACK 6 2 HOLES 14Ø 41 L 102x102x13 x298 LG LH 300W FB 6.4x38 x181 LG 300W, FB 6.4x58 x100 LG 300W, HEX BOLT M10x30 LG GR5, HEX NUT M10 C\W. FLAT WASHER 205 2551 549 594 W200x42 x1262 LG 300W 102 38 70 37 225 152 FB 13x152 x225 LG 300W HSS 102x102x6.4 350W
