A structural detail of a beam-to-column web connection frames beams of different depths into a common column. The shear tab thickness is specified as the beam web thickness plus one-quarter inch, with bolt sizes and counts determined per the schedule and plan. Top and bottom beam flanges are connected using continuity plates welded to the column flanges. A second row of bolts is included as required per the structural plans. Edge distances and bolt spacings conform to AISC specifications, and continuity plates are omitted on one side if the spacing is less than three inches.
BEAM TO COLUMN WEB CONNECTION A (DIFFERENT BEAM DEPTH) FOR EDGE DISTANCE AND BOLT SPACING SEE AISC SPECIF, TYP SHOWN ON PLAN THUS: No & SIZE OF BOLTS (SEE NOTE 3) 2ND ROW OF BOLTS AS REQUIRED, SEE PLAN TO STEEL CONTINUITY PLATE T&B (SEE DETAIL "E") SHEAR TAB THICKNESS = BEAM WEB THICKNESS + 1/4" IF LESS THAN 3" OMIT CONT PLATE THIS SIDE * SEE SCHED TF2 TF1 3" MIN TYP 2" TF1 TF2 TF1 TF2 CP T&B FLANGES, TYP UNO M *
