Reinforcing bar placement and lap splices around a small opening in a concrete shear wall. Additional reinforcement equal to half of the interrupted steel is added at the opening with four-inch spacing. Match bar sizes are provided for all interrupted reinforcement. Laps comply with shear wall elevation requirements up to a maximum two-foot dimension.
36" 36" 14 7/8" 14 7/8" 2'-0" MAX 2'-0" MAX Lsbt TYP LAP PER SW EL ADD REINF EQUAL TO HALF THAT INTERRUPTED AT OPENING @ 4" PROVIDE MATCH BAR SIZE TYP AT INTERRUPTED REINFORCEMENT SHEAR WALL Lsb 3 TYPICAL SMALL SHEAR WALL OPENING
