New cored holes are drilled through an existing concrete wall while avoiding existing reinforcing steel. Nondestructive testing is required to locate existing reinforcing bars prior to coring. Cored holes require a minimum clearance of three times the larger diameter from each other and a typical two-inch clearance from reinforcing. All cored hole locations must be reviewed and approved by the structural engineer of record prior to coring work.
MIN 3x LARGER DIA CLR (E) CONC WALL (E) REINF WHERE OCCURS (N) CORED HOLE ADDL (N) CORED HOLE WHERE OCCURS NOTES: 1. ALL CORED HOLE LOCATIONS SHALL BE REVIEWED AND APPROVED BY THE SEOR PRIOR TO CORING. 2. PROVIDE NONDESTRUCTIVE TESTING TO DETERMINE THE LOCATION OF (E) REINFORCING BARS PRIOR TO THE CORING OF (N) HOLES. LOCATE THE (N) CORED HOLES IN SUCH A MANNER TO AVOID CONTACT WITH (E) REINFORCING. MAX, TYP 6" MIN, TYP 2" CLR
