A metal floor deck runs parallel to an edge beam at an interior condition. A 1/4-inch closure plate caps the deck edge, anchored by #4 ASTM A706 rebar welded to the plate. A clip angle connects the assembly to wall studs by others where they occur. The steel deck bears on the supporting edge beam sized per plan.
DECK PARALLEL TO BEAM - INTERIOR CONDITION 7C 1'-0" MAX 2'-4" #4 ASTM A706 REBAR WELDED TO CLOSURE PLATE (SEE ALT 7F/-) WALLS STUDS BY OTHERS WHERE OCCUR EDGE BEAM PER PLAN CLOSURE PLATE 1/4" CLIP ANGLE PER WALL STUD DETAILS (SEE NOTE 1) 2" MIN 3/4", TYP 3/16 2-12 3/16 2-12 1/4 NOTE:
