A hollow structural section steel column is welded to a base plate containing four anchor bolts arranged symmetrically. Sixteen-millimeter stiffeners are welded to the column webs and the base plate to transfer loads effectively. Dimensions indicate spacing of forty millimeters, two hundred eighty-five millimeters total span, and equal spacing configurations. Additional sizing is noted as required per structural plans.
