Cold-formed metal studs interface with the perimeter framing through a delegated deflection clip connection tied back to the structure. A roof edge plate spans from the exterior stud assembly across the top flange of a structural steel beam. The roof deck bears over the steel framing assembly alongside a bolted framing connection at the beam and girder intersection.
GL GL B/ DECK ROOF RE PLAN T/WALL RE: ARCH INFILL STUD RE: ARCH ROOF EDGE PLATE RE BEAM RE PLAN GIRDER RE PLAN DEFLECTION CLIP AND CONNECTION (DELEGATED) COLD-FORMED METAL STUDS RE ARCH (DELEGATED) 1 S-61305
