A buckling-restrained braced frame brace connection frames directly into a column web. Plates are provided on both sides of the web matching the column web thickness with a one-half inch minimum. The gusset plate assembly aligns with the work point of the brace and buckling-restrained frame beam. Three-eighths inch fillet welds are specified typically on three sides for the connection elements.
BRACE TO COLUMN WEB B A W.P. CL OF BRBF BEAM PL BOTH SIDES OF WEB MATCHING COL WEB THK (1/2" MIN) CL OF BRACE 3/8 3/8 3 SIDES TYP 3/8 3/8 CONDITION WHERE OCCURS
