Six total number six vertical reinforcing bars are placed with bars on each face of the cores at the end or corner of a concrete masonry unit wall. Horizontal wall reinforcing extends through the cores with hooked anchorage at the jamb or corner condition.
TYPICAL HORIZ WALL REINF END OR CORNER OF CMU WALL, TYP 8" 8" #6 VERT EA FACE, TYP (6 TOTAL) 3" 2 7/8"
