Concrete wall intersections and corners feature typical vertical reinforcing bars arranged in either single or double layers. The assembly details include standard lap splices and standard hooks at corners and tee intersections. Four extra typical vertical bars are incorporated into the two-layer reinforcement option to accommodate increased structural demands. Standard lap dimensions govern the vertical bar splices throughout the wall heights.
TYP VERT BAR (AT WALLS) OPTIONS STD HOOK (4) TYP VERT BARS (AT WALLS) OPTIONS STD HOOK 4 EXTRA TYP VERT BARS (AT WALLS) A ONE LAYER REINFORCEMENT B TWO LAYERS REINFORCEMENT STD LAP STD LAP
