Stud rails cross the pour strip in a post-tensioned concrete slab with a typical one-inch clearance and a minimum twelve-inch dimension typically maintained. The layout references the structural plan for both the post-tensioned slab and the pour strip. Spacing for the stud rails is indicated across the joint.
TYP. 1" CLR. TYP. 12" MIN. TYP. S STUD RAILS CROSSING POUR STRIP POUR STRIP REF. PLAN P/T SLAB REF. PLAN
