Cold-formed steel stud webs feature allowable factory punchouts and field-cut holes with specified dimensional limits and edge distances. Factory punchouts are limited in dimension with maximum heights and widths, maintaining minimum end distances and center-to-center spacing along the stud web. Where penetrations exceed allowable limits, reinforcing plates are installed to upgrade the web per structural drawings.
24" MIN. WEB EXISTING PENETRATION PER HOLE UPGRADE - SEE 8/S250 DEPTH OF STUD 24" MIN. 4 1/2" MAX. TYP. TYPICAL STUD KNOCK OUT OR FIELD CUT HOLE 1 1/2" MAX. TYP. STUD AND PUNCHOUT TYP. ALLOWABLE STUD PUNCHOUT TYP. INFILL OF FACTORY STUD PUNCHOUT 6" MIN. A B A STUD MIN. DEPTH OF
