Concrete slab-on-grade conditions include a depressed slab transition and a thickened slab edge. The depressed slab detail accommodates a maximum four-inch depression with two continuous number four reinforcing bars, incorporating ninety-degree hooks at the step when the depression depth exceeds two inches. The thickened slab edge detail features a twelve-inch minimum depth below finished grade or paving, an eight-inch minimum base width, and a one-to-one sloped transition back to the main slab thickness reinforced with two continuous number four bars.
DEPRESSION "t" 4" MAX FIN GRADE OR PAVING SEE PLANS 2-#4 CONT PROVIDE 90° HOOK WHERE "t" EXCEEDS 2" MIN 8" 1'-6" MIN 6t OR MIN 12" 1 1 SLAB ON GRADE PER PLAN SLAB ON GRADE PER PLAN DEPRESSED SLAB DETAIL SLAB EDGE DETAIL 7B 7A SLAB ON GRADE EXPANSION JOINTS (WHERE NOTED) 2
