A Unistrut P1000 channel spans a minimum of four low flutes of the roof deck, secured by two number twelve self-tapping metal screws with lock washers in each low flute. A Unistrut P1354 hinge connector attaches to the channel using two 1/2-inch diameter A307 bolts on each leg, secured with P1010 channel nuts with springs. A diagonal Unistrut brace connects to the hinge connector to provide structural lateral support.
ROOF DECK PER PLAN UNISTRUT P1000 SPANNING MIN (4) LOW FLUTES W/ (2) #12 SMS EA LOW FLUTE W/LOCK WASHER EA SMS PERPENDICULAR CONDITION UNISTRUT P1354 HINGE CONNECTOR W/ (2) 1/2"Ø A307 BOLT EA LEG 1 1 (MAX) UNISTRUT DIAGONAL BRACE UNISTRUT P1010 CHANNEL NUT W/ SPRING, TYP
