A structural steel beam connects to a hollow structural section column in a two-way configuration utilizing a cap plate at the column top. Double rows of bolts fasten each side of the column connection as detailed in the elevation and plan views. Additional information and unnoted requirements are referenced to sheet S5.2.
DBL ROWS OF BOLTS ES OF COL AT CAP £ PLAN VIEW A A FOR INFORMATION NOT NOTED SEE 5 S5.2
